Product Specs
- Axles(2) 22500 Lb. Heavy Duty Axle Beams (5.0” Dia. x .50” Tube)
- BrakesFull Air on Both Axles with 16.5 x 7 Outboard Drums; Spring Park Brake; Automatic Slack Adjusters; and ABS
- Capacity48000 Lbs. GVWR
- Deck10' x 102" Upper Wood Deck
- Frame14" Wide-Flange Steel Beams
- Hubs10-Bolt on 11.25" Bolt Circle with Oil Bath Bearing Lubrication; Hub Pilot
- Jack10000 Lb. Top-Wind Drop-Leg
- LightsDOT compliant LED light package; with 7-Way ATA Connector
- SuspensionHutch 9700US-354 High-Arch Springs
- Tank3200 Gallon Liquid Tank; 24-Ton Dry Fertilizer Tenders; Feed Bodies; Flat Beds; Grain Boxes; and Other
- Tires255/70R-22.5 H-Ply Low Profile Radials
- Wheels(8) 22.5 x 8.25 x 10 - 11.25 Disc Type Duals; White
