Duo Lift SC3025 Tandem Axle Trailer
- Item #: 91702
Product Description
SC3025 Single Cone Bottom Transport w/ (2) 225/75R15D Ply Radial Tires Mounted on 15" 6 Bolt Silver Wheels, Pin-On Clevis Hitch and AG Lights.
Manual Hydraulic Pump with (2) Lift Cylinders(2) D.O.T. Safety ChainsPlatform in Tongue for Pump(2) Hose Storage Hooks Per Cone(4) Tank Tie Downs
Duo Lift provides Duo Lift ag parts such as the 91702 Duo Lift SC3025 Tandem Axle Trailer.
Product Specs
- Capacity3000 lbs Transport
- DimensionsLength……….183' Width………..8'Height with 2500 Gal. Tank …….151”Height with 3000 Gal. Tank …….171
- Frame6" Structural Channel
- HitchAdjustable Height Clevis
- Hubs611; 6-Bolt Circle; 3600 Lbs. Cap. Ea.
- Jack2000 Lb. Top Wind
- Lights Stop / Turn / Tail Function Red LED Lights with 7-way RV Connector
- Spindles2" Dia. 1144 Cold Rolled Shaft
- Tank(1) 2;500 or (1) 3000-gallon cone bottom; 15? slopetanks for portable field storage (tanks not included)
- Tires225/75R15D Radial Tire; 2540 Lbs Cap. Ea.
- Wheels15" x 6" x 6 - 6"; Silver
