Duo Lift LB1TXLB Low Profile
- Item #: 90558
Product Description
LB1TXLB, UNIVERSAL LOW-BOY WAGON, INCLUDES TANDEM ADJUSTABLE REAR AXLES 92-120", HEAVY DUTY EXTENSION TONGUE WITH SPRING LIFT ASSIST, 886 HUBS, 11.75 X 22.5 WHEELS WITH 385/65R22.5 USED SUPER SINGLE TIRES, 2-WHEEL HYDRAULIC BRAKES, ADJUSTABLE TANK LEG PADS TO ACCOMMODATE 1,000 OR 1,465 NH3 TANKS
5th wheel steering with 2: SAE, Heat Treated 75-Ton Semi Kin Pin Turnable, 20" Dia.
Adjustable tank supports to accommodate twin 1000 or 1450 NH3 or 2000 short or 3000 short tank
Heavy Duty Extension Tongue with Double Spring Lift Assist, (2) DOT 1/2" x 40" Safety Chains
NH3 Hose Routing Brackets, Removable Front Mounting Plate with (3) 1-1/4" Schedule 80 NH3 couplings installed, roll bar on front of gooseneck and ag conspicuity tape
Duo Lift provides Duo Lift ag parts such as the 90558 Duo Lift LB1TXLB Low Profile.
Product Specs
- Axles8” x 4” Heavy Wall Tubing with 2.75” Dia. Rocking Pin and Seamless (DOM) brushing
- Capacity32000 Lbs. GVWR; Weight: 4000 -4500 lbs
- Frame10" Wide-Flange Steel Beams and 6" Schedule 80 Round Torque Tube
- GooseneckDouble 8" X 4" Heavy Wall Rectangular Tube
- Hubs886; 8-bolt; 8000 lb; FRONT AND REAR
- LightsStop / Turn / Tail Function Red LED Lights with 7-way RV connector
- Spindles3” Dia. 1144 Shaft
- Tank(2) 1000 Gallon or (2) 1450-Gallon NH3 Tanks (1) 2000 Gallon Short Tank or (1) 3000 Gallon NH3 Tank
- Tires(6) 385/65R22.5 Used Super Single Tires
- Track WidthFront 60" Rear; Adjustable 92” - 120”
- Wheel Base16’-5” - first tire; 20’-10” second tire
- Wheels(6) 22.5 x 11.75 x 8 bolt 8” B.C. Silver Spoke
