Product Specs
- Axles8" x 4" Heavy Wall Tubing with 2.75" Diameter Rocking Pin and Seamless (DOM) Bushing
- Bale Cradles(3)120” made with 3.5” Heavy Wall round tube
- Capacity28000 lbs
- ColorTwo Part Gloss Black; Acid Etch Steel Prep.; All Weld Slag and Scale Removed Prior to Painting; Silver/Gray Wheels; Red; Orange and Yellow AG Reflective Conspicuity Tape
- DimensionsOverall Wagon Length32’4”; Bale Cradle Width 124.5”; Front Track Width 60”; Rear Track Width 92”
- Equipment Weight4400 LBS
- Frame(2) 10" x 4" - 22# Wide Flange Beams with (1) 6" Heavy Wall Torque Tube and Front Roll Guard
- GooseneckDouble 8" x 4" Heavy Wall Rectangular Tube
- Hitch1/2" Thick and Reinforced Rear Hitch Plate with (2) Safety Chain Hook Locations
- Hubs(2) 819; (2) 886
- LightsAg Light Package with 7-way RV connector and LED lights
- SpindlesFRONT: 2.5"; REAR: 3"
- Steering5th Wheel with 2" SAE Heated Treated; 75 Ton Semi King Pin welded to 20" Diameter Turntable
- Tires(4) 385/65R22.5 Used Super Single Tires
- Tongue4" x 3" Heavy Duty Tubing; 78" Length with (2) Grade 70; 1/2" x 40" Safety Chains with Load Rating Tags
- Warranty5-year main frame; 1-year component
- Wheels(4) 22.5" x 11.75"; 8-Bolt Silver/Gray HD Spoke Wheels
